J Series Jaw Crushers
The J Series Jaw Crushers are durable and efficient, providing high productivity for your operations. The aggressive design, with a low-positioned, short toggle in combination with a deep cavity and optimized nip angle, results in a jaw crusher with large throughputs at a high reduction ratio. The symmetrical chamber also minimizes slippage, which reduces jaw plate wear.
Product Features
- Bolted, non-welded frame construction with premium quality castings and components
- Hydraulic wedge adjustment allows for push button control of closed side settings
- Aggressive nip angle ensures the jaw consistently processes material and maintains capacity throughout liner life
- Replaceable toe on both pitman and frame which prevents the need for welding up these areas as the jaw ages
- Both the pitman and frame have replaceable backing plates that protect the parent part should the jaw die wear through
Metric
Imperial
Technical Parameter Table
|
Model
|
Maximum Feed Size (mm) | Capacity (mtph) | Motor Power (kW) |
|---|---|---|---|
| J35 | 400 | 100 – 280 | 55 |
| J40 | 500 | 130 – 360 | 75 |
| J45 | 650 | 220 – 600 | 110 |
| J50 | 800 | 300 – 850 | 160 |
| J55 | 900 | 410 – 1,000 | 200 |
| J65 | 1,000 | 550 – 1,100 | 250 |
| J80 | 1,250 | 720 – 1,600 | 400 |
| J3055 | 610 | 240 – 680 | 160 |
| J3355 | 700 | 320 – 750 | 160 |
| J3448 | 700 | 180 – 540 | 160 |
