Fine Material WashersGlobal Supplier & Manufacturer of Mineral Processing Solutions
AMPCO Minerals Fine Material Washers hydraulically split finer sized materials making a high-quality finished sand product. Our washers have a heavy-duty steel tub, adjustable overflow weirs, and can operate at variable speeds for optimized classification and dewatering of fine material. They are easy to maintain with our replaceable wear parts to help extend their operating life.
Product Features
- Heavy-duty, thick washer box
- Thick wall seamless steel tub shafts
- Adjustable weirs
- Easy to change cast flight shoes
- Flushing water port(s) for dewatering
- Common wear parts
- Easy to change lower bearing assembly with rotatable wear sleeve for extended life
- Heavy-duty gearbox
- Available in single or twin configurations
Metric
Imperial
Technical Parameter Table
|
Model
|
Diameter (mm) | Length (m) | Maximum Capacity (mtph) | Maximum Feed Size (mm) | Motor Power (kW) | Water Volume (lpm) |
|---|---|---|---|---|---|---|
| FW3625 | 915 | 8 | 90 | 10 | 11 | 150 – 1,367 |
| FW4432 | 1115 | 10 | 155 | 10 | 18.5 | 233 – 2,800 |
| FW5434 | 1370 | 10 | 245 | 10 | 30 | 233 – 3,600 |
| FW6636 | 1676 | 11 | 360 | 10 | 45 | 233 – 4,350 |
| FW3625D | 915 x 2 | 8 | 180 | 10 | 11 x 2 | 400 – 2,350 |
| FW4432D | 1,115 x 2 | 10 | 315 | 10 | 18.5 x 2 | 483 – 5,300 |
| FW5434D | 1,370 x 2 | 10 | 495 | 10 | 30 x 2 | 483 – 6,433 |
| FW6636D | 1,676 x 2 | 11 | 720 | 10 | 45 x 2 | 483 – 9,497 |
| FW7238D | 1,830 x 2 | 12 | 860 | 10 | 75 x 2 | 483 – 11,667 |
